| Types | Rated voltage | Operating voltage range | Rated current | Input power | Rated speed | Maximum air volume | Maximum static pressure | Noise | ||
| [V] | [V] | [A] | [W] | [RPM] | [m3/h] | [CFM] | [mmAq] | [Pa] | [dB(A)] | |
| NDS12038C12XA | 12 | 6~13.8 | 0.80 | 9.60 | 3700 | 255.6 | 150.7 | 13.4 | 130.8 | 49.0 |
| NDS12038C24XA | 24 | 12~27.6 | 0.40 | 9.60 | 3700 | 255.6 | 150.7 | 13.4 | 130.8 | 49.0 |
| NDS12038B24XC |
24 |
12~27.6 |
0.16 | 3.84 | 2500 | 159.6 | 94.2 | 5.46 | 53.5 | 30.0 |
| NDS12038C24XC |
24 |
12~27.6 |
0.45 | 10.80 | 3500 | 239.4 | 141.0 | 9.65 | 94.6 | 42.0 |
| NDS12038H24SC |
24 |
12~27.6 |
4.80 | 115.00 | 8000 | 582.6 | 343.2 | 68.1 | 667.6 | 76.0 |
| NDS12038C48XC |
48 |
36~54.0 | 0.23 | 11.00 | 3800 | 162.0 | 95.0 | 16.4 | 161.0 | 46.0 |
| NDS12038E48XA |
48 |
36~54.0 |
0.95 | 45.60 | 5200 | 411.6 | 242.3 | 31.5 | 308.5 | 58.0 |
| NDS12038K48XC |
48 |
36~54.0 |
1.40 | 67.00 | 10000 | 432.0 | 254.0 | 107.0 | 1050.0 | 72.0 |
|
DS12038K48XC |
48 |
36~54.0 |
2.00 | 96.00 | 11500 | 498.0 | 293.0 | 132.5 | 1300.0 | 75.0 |
|
RP |
SS | AS | CL | OV | CS |
| 反接保护 | 软启动 | 锁定保护 | 限流保护 | 过压保护 | 恒速保护 |
| Default | Default | Default | Optional | Optional | Optional |
| FG | RD | LD |
| 转速侦测 | 停转告警 | 设定告警 |
| Optional | Optional | Optional |
| PPWM | VPWM | TC | RC |
| 占控比调速 | 电压调速 |
温控调速 |
电阻调速 |
| Optional | Optional | Optional | Optional可选 |
